| MODEL |
ATSP-120 |
ATSP-130 |
ATSP-216 |
ATSP-232 |
| INPUT |
Voltage Range(VAC) |
75 ~ 150VAC |
150 ~ 300VAC |
| Voltage(VAC) |
100 / 110 / 115 / 120 / 127VAC ± 5% / 10% / 15% / 20% |
200 / 208 / 220 / 230 / 240VAC ± 5% / 10% / 15% / 20% |
| Frequency Range(Hz) |
50 / 60Hz ± 5% / 10% / 15% / 20% |
| Current(Amp) |
20A |
30A |
16A |
32A |
| OUTPUT |
Voltage(VAC) |
100 / 110 / 115 / 120 / 127VAC |
200 / 208 / 220 / 230 / 240VAC |
| Current(Amp) |
20A |
30A |
16A |
32A |
| CONNECTION |
Input |
(2) NEMA 5-20 |
(2) NEMA L5-30 |
(2) IEC 320-C20 |
Terminal Block |
| Output |
(8) NEMA 5-20 |
(8) NEMA 5-20
(1) NEMA L5-30 |
(8) IEC 320-C13
(1) IEC 320-C19 |
Type A: Terminal Block
(12) IEC 320-C13,
(2) IEC 320-C19 |
Type B: Terminal Block
(16) IEC 320-C13,
(2) IEC 320-C19 |
| PROTECTION |
Circuit breaker (option) |
| Electronic circuit |
| COMMUNICATION |
Standard |
RS-232, USB, Dry contact, EPO, Slot |
| Interface (Option) |
RS-485, SNMP/WEB card (option) |
| TRANSFER TIME (ms) |
8 ~ 12ms (Typical) |
| EFFICIENCY |
99%(with full linear load) |
| INDICATOR |
LCD + LED |
| PHYSICAL |
Dimensions (WxHxD in mm) |
440 x 44 x 275 |
440 x 88 x 275 |
440 x 44 x 275 |
440 x 88 x 275 |
| Net Weight (kgs) |
4 |
6 |
4 |
6 |
| ENVIRONMENT |
Operation Temperature |
-5 ~ 40°C |
| Operation Humidity |
5 ~ 90%RH, non-condensing |
| Altitude |
2000m without derating |
STANDARDS &
CERTIFICATIONS** |
Safety |
UL 60950-1/ CAN/CSA C22.2 No. 60950-1 / IEC 60950-1 (on going) |
EN 60950-1 |
| EMC |
FCC Part 15 / EN62310-2 (on going) |
EN 62310-2 |
| Markings |
UL |
CE |
| Note |
*60Hz: 16ms (max.), 50Hz: 20ms (max.) |
*60Hz: 16ms (max.), 50Hz: 20ms (max.) |
|
| * Specifications subject to change without notice, and the final explanation rights are reserved by Ablerex. |
| ** Depending on the model and rating voltage, please contact Ablerex for more information. |
| *** The same technical specification may be sold in diferent countries under different model names, please consult Ablerex for more information. |
|
