| MODEL |
Glamor Sine 600 |
Glamor Sine 800 |
Glamor Sine 1000 |
Glamor Sine 1500 |
Glamor Sine 2000 |
| INPUT |
Voltage Range(VAC) |
165 ~ 290VAC |
| Frequency Range(Hz) |
50 / 60Hz ± 5Hz (auto sensing) |
| OUTPUT |
Capacity(VA/W) |
600 / 420 |
800 / 560 |
1000 / 700 |
1500 / 1050 |
2000 / 1400 |
| Voltage(VAC) |
220 / 230 / 240VAC (default 230VAC) |
| Voltage Range(VAC) @ Battery Mode |
220 / 230 / 240VAC ± 10% |
| Frequency Range(Hz) @ Battery Mode |
50 / 60Hz ± 0.5Hz |
| Transfer Time |
6ms (typical) |
| Waveform @ Battery Mode |
Pure sine waveform |
| BATTERY |
Battery Type |
VRLA, sealed lead acid maintenance free |
| Capacity and Number |
12V / 7Ah x 1 |
12V / 9Ah x 1 |
12V / 7Ah x 2 |
12V / 9Ah x 2 |
12V / 9Ah x 2 |
| Voltage(Vdc) |
12 |
12 |
24 |
24 |
24 |
| Typical Charger Time |
4 ~ 6 hours recover to 90% capacity |
| INDICATOR |
LED |
3 LEDs: Line mode, Battery mode and Fault |
| LCD (Option) |
Line mode, AVR mode, Battery mode, Battery capacity, Load level, Input voltage, Output voltage, Fault and Battery weak |
| ALARM |
Audible or Visual |
Battery mode, Low Battery, Overload and Fault |
| OUTLET |
Backup |
(4) IEC 320-C13 |
(6) IEC 320-C13 |
| PROTECTION |
Full Protection |
Overload, Discharge, Overcharge, ABDM, Short circuit and RJ-11 / RJ-45 surge protection (Option) |
| FUNCTION |
DC Start |
Yes |
| AC Auto Restart |
Yes |
| Plug-in Charging |
Yes |
| ABDM |
Yes |
| A.V.R |
Boost x 1 and Buck x 1 |
| PHYSICAL |
Dimensions (WxHxD in mm/inch) |
116 x 171 x 305 / 4.6 x 6.7 x 12.0 |
165 x 198 x 393 / 6.5 x 7.8 x 15.5 |
| Net Weight (kgs) |
5.5 / 12.1 |
7.1 / 15.7 |
9.3 / 20.5 |
12.4 / 27.3 |
12.6 / 27.8 |
| Shipping Weight (kgs) |
6.2 / 13.7 |
7.8 / 17.2 |
10.3 / 22.7 |
13.4 / 29.5 |
13.6 / 30.0 |
| ENVIRONMENT |
Operation Temperature |
0 ~ 40°C / 32 ~ 104℉ |
| Storage Temperature |
-15 ~ 50°C / 5 ~ 122℉ |
| Operation Humidity |
0 ~ 90%RH, non-condensing |
| Altitude |
1000meters without derating |
| Noise Level |
< 40dBA @ 1 meter front |
< 45dBA @ 1 meter front |
| COMMUNICATION |
Interface (Option) |
USB, RS-232 |
| Compatible Platforms |
Microsoft Windows series, Linux, Mac, etc. |
STANDARDS &
CERTIFICATIONS** |
Safety |
IEC EN 62040-1 |
| EMC |
IEC EN 62040-2, EN61000-3-2, EN61000-3-3 |
| Marks |
CE |
|
| * Specifications subject to change without notice, and the final explanation rights are reserved by Ablerex. |
| ** Depending on the model and rating voltage, please contact Ablerex for more information. |
| *** The same technical specification may be sold in diferent countries under different model names, please consult Ablerex for more information. |
|
